Automated panel stacking machine

FOB Reference Price:Get Latest Price
US $21,000-29,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Five Star
After-sales Service Provided:
Engineers available to service machinery overseas
Brand:
Five star
Color:
Customer's Requirement
Model Number:
PR10
Supply Ability
Supply Ability:
120 Set/Sets per Year
Packaging & Delivery
Packaging Details
As customer request
Port
Shanghai

Product Description

PR10 2.jpg





Description

The automated Panel Stacking Machine is a stacking machine used to arrange the panel assemblies into a fixture for the secondary welding operations. As panel assemblies are completed on the production line, each assembly is lifted from the conveyor and lowered to the staging array fixture. When the staging array fixture is full, it can be moved to the Horizontal Assembly Fixture for welding of header pipes to panel assemblies (Independent Machine). Another staging array fixture can then be loaded to the assembly for staging the next panel assembly.

Main parts' brand

PLC

Mitsubishi

Servo Systems

Mitsubishi

Pneumatics

Airtac

Drive gear

China

Hydraulic



 China
